SPECIFICATIONS
VBOX-Plus Gateway Specifications
Specification
Description
Power Supply
24 VDC, 100mA (see note below)
RS-232 Port
Bi-directional, DB-9 connection
RS-485 Port
Bi-directional
Ethernet Port
10 Base-T
USB Port
One, type B
Mounting
DIN
Dimensions
10 (W) x 9(H) x 4(D) cm
VTouch-Plus Keypad Specifications
Specification
Description
Power Supply
12-24 VDC, 10mA
RS-485 Connection
Bi-directional
Fits into Wall Mounting Box
Italian Module 3
Background Light
Blue, adjustable intensity
Button LED
Orange
Power Consumption
The 24 VDC power supply delivers power to the keypads via two wires of the 4-wire bus.
 Maximum current consumption per keypad: 10 mA
 Maximum current consumption of VP Gateway: 100 mA.
 Total maximum current consumption: (50 (keypads) * 10 mA) + 100 mA for the VP Gateway =
600 mA.
