Recommended Distance for Side-by-Side Keypads
Keypad A
Keypad B
Recommended distance
between glass panels (cm)
Horizontal distance between
centers of mounting boxes (cm)
Vertical
Vertical
2
12
Horizontal
Horizontal
2
14
Recommended Distance for Keypads One above the Other
Keypad A
Keypad B
Recommended distance
between glass panels
(cm)
Vertical distance between centers
of the mounting boxes (cm)
Vertical
Vertical
2
14
Horizontal
Horizontal
2
12
If the recommended distance between glass panels is not followed, the distance between the centers
of the wall mount boxes should be adjusted accordingly.
For best results (esthetically and functionally) it is recommended to place the keypads at a height of
120 cm from the floor.
