– 39 –
ADJUSTMENT HORIZONTAL VERTICAL
Keystone Max. +/– 35° approx. Max. +/– 40° approx.
The following are conditions under which the maximum angle is achieved:
When the standard lens (GB940G) is used
When the lens shift is set to H for center and V for 0.5 shift.
When the lens shift is used and yet you do not get the above-mentioned condition (H for center
and V for 0.5 shift), you cannot adjust the lens shift correctly.
Image is projected in Wide mode
Resolution is WXGA
Note:
Higher resolution than WXGA narrows the adjustable range.
Menu items should be set as follows:
Aspect Ratio ........... 16:10
Horizontal and Vertical are adjusted separately.
A combination of both adjustments narrows the adjustable range.
To Next Page
