The projection lamp should be replaced when it burns out. It should only be replaced with a certified
replacement part, which you can order from your local dealer.
Important:
a. The lamp contains a certain amount of mercury and should be disposed of according to local ordi-
nance regulations.
b. Avoid touching the glass surface of the new lamp: Doing so may shorten its operation life.
Warning:
Be sure to turn off and unplug the projector at least 30 minutes before replacing the lamp. Failure to
do so could result in a severe burn.
Note:
Safety glasses should be worn when replacing the lamp while the projector is ceiling mounted.
1.
Remove the four screws on the
lamp cover (A), and lift the lamp
cover as shown (B).
A
B
2.
Loosen the two captive screws
on the lamp module (A). Lift the
module handle up as shown (B).
A
B
– 81
–
