STEP 8: Manage Cables
STEP 9: Connect AC Adapter
Remove the adhesive backing from Cable Clips (J) and place them on the side of Mount (A).
Route Cables through Cable Clips (J) and use Cable Ties (I) to fasten cables to the side of the arm.
J (x2)
Cable Clip
I (x4)
Cable Tie
Plug AC Adapter (G) into Mount (A), and connect to AC outlet. Follow Remote (H) instructions for
operation.
H (x1)
Remote
G (x1)
AC Adapter
A
J
I
A
G
H
