VIVOTEK
50 - User's Manual
Media > Audio
Audio Settings
Mute: Select this option to disable audio transmission from the Network Camera to all clients. Note that
if mute mode is turned on, no audio data will be transmitted even if audio transmission is enabled on the
Client Settings page. In that case, the following message is displayed:
Internal microphone input gain: Select the gain of the internal audio input according to ambient
conditions. Adjust the gain from -33dB (least) to 21dB (most), which is corresponding to the numbers on
the slide bar.
Audio type: Select audio codec AAC, GSM-AMR, or G.711 and the bit rate.
■ G.711 also provides good sound quality and requires about 64Kbps. Select pcmu (μ-Law) or pcma
(A-Law) mode. pcma provides a better quality.
When completed with the settings on this page, click Save to enable the settings.
