VIVOTEK
User's Manual - 9
IMPORTANT!
Before installing your camera, make sure the built-in PIR (Passive Infrared Sensor) can
be directed toward the area of interest, where intrusions may occur� (The sensitivity of
PIR sensor depends on the object size and temperature differences between the object
and the background environment�)
50
50
5m
41
41
5m
Installation
Removing Dome Cover
Use the included T10 Torx screwdriver to loosen screws on the sides of dome cover to
remove it� You should then jot down the MAC address printed on the bottom of the camera�
Dome Cover
Bottom of the Camera
To Next Page
