VIVOTEK
User's Manual - 11
1� Attach the alignment sticker to the ceilling/wall�
2� Through the two circles on the sticker, drill two pilot holes into the ceilling/wall�
3� The Network Camera can be mounted with the cable routed through the ceiling/wall or
from the side� If you want to feed the cable through the ceiling/wall, drill a cable hole�
4� Hammer the supplied plastic anchors into the holes�
5� Align the holes on the camera with the plastic anchors on the ceilling/wall, secure the
camera with the included screws�
Wall Mount
Ceiling Mount
1� Install the "Installation Wizard 2�"
2� The program will search for VIVOTEK Video Receivers, Video Servers or Network Cam-
eras on the same LAN�
3� Double-click on the camera's MAC address to open a browser management session
with the camera�
Assigning an IP Address
To Next Page
