VIVOTEK
User's Manual - 15
Physical Description (FD8381-EV)
IR LEDs (4 units, effective
up to 30m)
Inner View
Vari-focal Lens
Tilt Adjustment Screw
Ethernet 10/100
RJ45 Socket
Audio/Video Out
(green)
Microphone In (pink)
General I/O Terminal Block
Jumpers
Video Output
NTSC
60Hz
PAL
50Hz
2
Focus & Zoom Buttons
Record the MAC address before
installing the camera�
0002D10766AD
FD8381-EV
MicroSD/SDHC/SDXC Card
Slot
Reset Button
