Vivotek FD8381-EV - Adjusting the Lens

VIVOTEK
12 - User's Manual
1
2
Tilt Adjustment Screws
Adjust the camera lens to the desired viewing angle:
1� Loosen the tilt adjustment screws on both sides
2� Turns the lens modules toward the direction you prefer�
3� Tighten the adjustment screws�
Pan 350°
Tilt: 65°
Rotate 350°
Adjusting the Lens
