VIVOTEK - A Leading Provider of Multimedia Communication Solutions
106 - User's Manual
Fluorescent, 5500K
Outdoor, > 5500K
atwbvalue 0 ~ 9999999999 4/4 The auto white balance value.
atwbvalue2 0 ~ 9999999999 4/4 The auto white balance value.
exposurelevel 1~8 4/4 Exposure level (product dependent)
autoiris <boolean> 4/4 Enable auto Iris.
(product dependent)
agc 0~2 4/4 Set auto gain control to normal level or MAX level.
(product dependent)
enablewdr <boolean> 6/6 Enable/disable WDR
Group: videoin_profile_i<0~(m-1)>
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable/disable this profile setting
policy day,
night,
schedule
4/4 The mode which the profile is applied to.
begintime hh:mm 4/4 Begin time of schedule mode.
endtime hh:mm 4/4 End time of schedule mode.
autoiris <boolean> 4/4 Enable auto Iris.
(product dependent)
exposurelevel 1~8 4/4 Exposure level (product dependent)
maxexposure 1~120 4/4 Maximum exposure time.
agc 0~2 4/4 Set auto gain control to normal level or MAX level.
(product dependent)
enablewdr <boolean> 6/6 Enable/disable WDR
enablewdr <boolean> 6/6 Enable/disable WDR
Group: videoin_c<0~(n-1)> for n channel products, and m is stream number
NAME VALUE SECURITY
(get/set)
DESCRIPTION
color 0, 1 4/4 0 =>monochrome
1 => color
flip <boolean> 4/4 Flip the image.
mirror <boolean> 4/4 Mirror the image.
ptzstatus <integer> 1/7 A 32-bit integer, each bit can be set separately
as follows:
Bit 0 => Support camera control function;
