VIVOTEK
4 - User's Manual
Physical Description
Front Panel
Back Panel
Connectors
IR LED
Lens
Light Sensor
Reset Button
Status LED
Ethernet 10/100 RJ45 Plug
Power Cord Socket (black)
General I/O Terminal Block
