Back Panel
MAC:0002D132C353
IP8132
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
General I/O Terminal
Block
Recessed Reset Button
Power Cord Socket
Ethernet 10/100 RJ45 Socket
Privacy Button
2
MAC:0002D132C353
IP8133W
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
IP8133 & 8133W
IP8132
Privacy Button
Antenna
Connector
(IP8133W)
Power Cord
Socket
WPS Button
(IP8133W)
Reset Button
Ethernet 10/100
RJ45 Socket
Antenna
Connector
(IP8133W)
General I/O
Terminal Block
NOTE:
Two antennas come with the IP8133W� They are
installed by users by turning clockwise to attach to
connectors�
