VIVOTEK
User's Manual - 75
A green bar indicates that even though motions have been detected, the event has not been triggered
because the image variations still fall under the dened threshold.
If you want to congure other motion detection settings for schedule mode, please click Prole to open
the Motion Detection Prole Settings page as shown below. A total of three motion detection windows
can be congured on this page as well.
Please follow the steps below to set up a prole:
1� Create a new motion detection window�
2� Check Enable this prole�
3� Manually enter a time range for Schedule mode�
4� Click Save to enable the settings and click Close to exit the page�
This motion detection window will also be displayed on the Event Settings page� You can go to
Application > Event Settings > Trigger to choose it as a trigger source� Please refer to page 83 for
detailed information�
Percentage = 30%
Video(TCP-AV)
2011/01/17 13:44:17
