Vivotek IP8173H - Mounting the Lens to the Camera

VIVOTEK
User's Manual - 7
Lens
Focus Controller
Zoom Controller
Mounting the Lens to the Camera
1� Mount the lens by turning it clockwise onto the camera mount until it stops�
2� Connect the iris control cable to the socket� Connect the iris control cable before
power-on. Otherwise, you will not be able to access the exposure-related settings.
2
1
