VIVOTEK - Built with Reliability
User's Manual - 125
Login / Logout
3-5-20. Settings–User
The User window allows you to create more users, to change user password, and place
limitations on users' privileges and administration rights. Up to 16 users can be created,
including the default administrator.
1. By default, there are two user groups: Administrator and Regular user.
2. The regular users cannot access the Settings window, meaning that regular users can not
add or remove cameras, make changes to alarm, network, and all other system settings.
When users try to access the Settings window, the login window prohibits regular users to log
in. There is simply no regular user's name on the login window.
3. The administrator users can access all cameras recruited in the conguration; while the
regular users can be congured to have access to some or all cameras.
4. The system blocks out the video feeds from users who are denied of the access to particular
cameras. The alarms and the alarm-triggered recordings from those cameras will also be
inaccessible for unauthorized users.
The default administrator name and password are: admin and admin. It is highly recommended
to change the default password to prevent unauthorized access to the system.
IMPORTANT:

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vivotek ND9323P and is the answer not in the manual?

Vivotek ND9323P Specifications

General IconGeneral
Recording modesContinuous, Event, Manual, Schedule
Maximum resolution3840 x 2160 pixels
Throughput data rate88 Mbit/s
Video input channels8 channels
Audio formats supportedG.711, G.726
Image formats supportedJPEG
Video formats supportedH.264, H.265, M-JPEG
Operating system installedEmbedded LINUX
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)175 W
Total Power over Ethernet (PoE) budget120 W
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 95 %
CertificationCE, FCC, VCCI, C-Tick, UL, CB, BSMI, BIS
LED indicatorsYes
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocolsIPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Wi-Fi-
HDD size3.5 \
RAID levels0, 1
HDD capacity- GB
Maximum storage capacity- TB
Number of HDDs supported2
Weight and Dimensions IconWeight and Dimensions
Depth320.3 mm
Width366 mm
Height46 mm
Weight2500 g
