24 - User's Manual
1. The maximum decoding bandwidth is
H.265
3840x2160@30fps 1 CH
1920x1080@120fps 4 CH
H.264
3840x2160@30fps 1 CH
1920x1080@120fps 4 CH
Recording throughput:
64Mbps (ND9323P / ND9425P)
Note that when accessed over the network, the total streaming throughput is 88Mbps.
Pre-recording: 5 seconds (max. 10)
Post-recording: 20 seconds (max. 300)
When cameras are recruited into the conguration, their stream 1 is used as the recording
stream.
The resolution and fps (frame rate per second) of stream 1 may vary depending on the
specications of di󰀨erent cameras.
2. If there are less than 8 or 16 cameras, the Auto Setup will automatically move to the next
conguration step.
NOTE:
