7.27 Storage management setting
Currently it’s for local storage (SD, CF card)
Group: disk_i<0~(n-1)> n is the total number of storage devices. (capability.storage.dbenabled > 0)
PARAMETER VALUE Default SECURITY
(get/set)
DESCRIPTION
cyclic_enabled <boolean> 0 6/6 Enable cyclic storage method.
autocleanup_enabled <boolean> 0 6/6 Enable automatic clean up method.
Expired and not locked media files
will be deleted.
autocleanup_maxage <positive
integer>
7 6/6 To specify the expired days for
automatic clean up.
7.28 Region of interest
Group: roi_c<0~(n-1)> for n channel product, and m is the number of streams which support ROI.
(capability.eptz > 0)
PARAMETER VALUE Default SECURITY
(get/set)
DESCRIPTION
s<0~(m-1)>_home "0~1104","0~6
56"
0,0 6/6 ROI left-top corner coordinate.
s<0~(m-1)>_size "176~1280"x"1
44~800"
1280x800 6/6 ROI width and height. The width
value must be multiples of 16 and the
height value must be multiples of 8
