VIVOTEK
User's Manual - 21
Left
Down
Start to Auto Patrol
Start to Auto Pan
Stop Auto Panning/patrolling
Return to Home Position
Right
Up
VIVOTEK INC. Logo
Click this logo to visit the VIVOTEK website.
Host Name
The host name can be customized to t your needs. For more information, please refer to System on page 30.
Camera Control Area
Video Stream: This Network Camera supports multiple streams (stream 1 ~ 4) simultaneously. You can
select either one for live viewing. For more information about multiple streams, please refer to page 56
for detailed information.
Manual Triggers: Click to reveal the manual trigger buttons.
PTZ Control Panel:
Pan: Click this button to start the auto pan (will pan 180° to one side, pan 180° to the other, and then
return to the home position).
Stop: Click this button to stop the Auto Pan and Auto Patrol action.
Patrol: Once the Administrator has congured the list of preset positions, click this button to command
the camera to patrol among those positions on the Patrol List. The Network Camera will patrol through
the preset positions for one time. For more information, please refer to PTZ control on page 81.
The onscreen Java control can malfunction under the following situations:
A PC connects to different cameras that are using the same IP address (or the same camera
running different rwmare versions).
Removing your browser cookies will solve this problem.
Tips:
