Vixel 9000 series User Manual

47
APPENDIX A Physical
Description
Vixel 9000 Series Fibre Channel Switches have the following physical features:
• A compact 1U size for easy installation into standard rack or onto tabletop.
• Eight ports for the Vixel 9100; sixteen ports for the Vixel 9200 & Vixel 9300.
• Redundant power supplies for the Vixel 9300.
• System and port status indicators.
• Bandwidth of 32 Gb/s for Vixel 9100 and 64 Gb/s for Vixel 9200 & Vixel 9300.
• Fully non-blocking architecture.
• User-defined buffering for up to 32 maximum size frames per port.
• Hardware-implemented routing with a route determination time less than two
micro-seconds.
• An auto-sensing power supply that supports 100VAC through 250VAC,
50 or 60 Hz.
Power Supply
The universal power suppl(ies) are auto ranging and sense both the frequency (50 or
60 Hz) and input voltage for voltages between 100VAC through 250VAC.
Power Supply 47
Ports and LEDs 48
Operating Conditions 51
