Vixel 9000 Series Installation & Configuration Guide APPENDIX C Troubleshooting
57
4. If you plan to run the Diagnostic External LoopBack Test, ensure that the
necessary copper or optical Fibre Channel loopback plugs are inserted before
the switch is powered on.
5. Power on the switch (reconnect the power cord).
6. While the yellow 10/100 LED (located on the right side of the switch) is
illuminated, press Enter repeatedly (two depressions of the Enter key must be
detected).
Note: Do not use the Diag-
nostic Options Menu.
These options are for
factory use only.
An information display similar to the following appears. Be prepared to discuss
the results with an authorized service person.
-----------------------------------------------------------------------------
VIXEL Model 9100 VIXEL Corporation(TM)
Diagnostic Analysis
---- Devices ----------------------- Result -- Information --
Flash Memory Checksum ............. PASSED
SDRAM Memory (16M)................. PASSED
Real Time Clock (RTC) ............. PASSED
Asynchronous (ART) ................ PASSED
PCI Bridge and Ethernet Device .... PASSED
Route Timer/Table/Address Devices . PASSED
Port Control Devices .............. PASSED
FPP Devices ....................... PASSED
Internal Port Loopback Tests ...... PASSED
Parity Analysis ................... PASSED
Fan 1,2,3 & 4 Status............... PASSED
========== System Information ==========
Model: 00301563-901-A
End Item Serial Number: Z16D3000110
Port Count: 8
FPP Versions Match: Y
Board Serial #: Z18D3000134
Serial Prom Revision: 2
Slip IP Address: 192-168-2-129
Slip IP Mask: 255-255-255-0
Ethernet Address: 00-10-9b-82-04-1c
Ethernet IP Address: 192-168-1-129
Ethernet IP Mask: 255-255-255-0
Ethernet IP Gateway: 0.0.0.0
Firmware Version: 5.0.166
Image Booted: Image2
NVRAM Revision: 01
Manufacture Date, Time: 02-25-2000 11-48-52
<< Diagnostic Options Menu >>
Option 2 System must be Rebooted.
1) FPP Diagnostic Testbench
2) Switch Boot to Alternate Image
3) Set MGMT Port to NVRAM Utility
4) Continue System Boot to Switch
Select System Diagnostic Option :
