STRUCTURE - START-UP
3.2.4 CABLE CASE
1 Umbilical cable for VUSCREEN
2 Ground connector cable
3 Power cord D / UK / US
1 2 3
3.2.5 ACCESSORY CASE
1 Centering device kit (depending on model)
2 Mounting clip for pushing aid
3 Mounting adapter for LCD control pendant
4 External air supply adapter
5
Force deection ball for optional pushing
aid
6 optical adapters (optional)
7 USB device
8 Camera head protection ring
9 Mounting tool
1
2
5
6
7
8
9
3
4
