Vizio D50-F1 User Manual

3
ADJUSTING THE AUDIO SETTINGS
To adjust the audio settings:
1. Press the Menu button on the
remote. The on-screen menu
is displayed.
2. Use the Arrow buttons on the
remote to highlight Audio and
press OK. The AUDIO menu
is displayed.
3. Use the Arrow buttons to
highlight the setting you wish
to adjust, then press Left/
Right Arrow buttons to change
the setting:
• Speakers - Turns the built-in
speakers On or O.
• Volume Control Display - Toggle between On or O to
hide or display the on-screen volume slider that appears
when volume is adjusted.
• Surround Sound - Surround sound uses DTS TruSurround
™
to deliver an immersive surround sound experience from
the TV’s internal speakers. TruSurround completes the
entertainment experience by providing deep, rich bass
and by delivering crisp details and clear, intelligible dialog.
Select On or O.
• Volume Leveling - Volume leveling uses DTS TruVolume
™
to maintain consistent volume levels during transitions
between program content, AV formats, and input sources.
Select On or O. In a few cases, volume leveling may
articially suppress volume increases, making it dicult to
hear dialog or attening sudden noises. If this occurs, turn
volume leveling o.
When the TV speakers are set to On, DTS signals
cannot be passed through digital audio outputs.
• Balance - Adjusts the loudness of the audio output from the
left and right speakers.
• Lip Sync - Adjusts the synchronization between the display
image and the accompanying audio track.
• Digital Audio Out - Changes the type of processing for
digital audio out and HDMI ARC output when connected to a
home theater audio system. Select Auto, PCM, Dolby D or
Bitstream.
• Analog Audio Out - Sets the volume control properties for
the RCA connector when connected to a home theater audio
system. Select Variable if you are controlling the volume with
the TV’s volume controls, or select Fixed if an external audio
device (sound bar or AV receiver) will control the volume.
• Equalizer - Adjusts the boost or attenuation of dierent
frequencies using either preset or custom settings. See
Changing the Equalizer Settings .
4. When you have nished adjusting the audio settings, press the
Exit button on the remote.
You must select Bitstream for audio with more than
two channels (3.0, 5.0, or 5.1, for example).
Audio
Speakers Auto
Volume Control Display On
Surround Sound On
Volume Leveling Off
Balance 0
Lip Sync 0
Digital Audio Out Auto
Analog Audio Out Fixed
Back
21

Vizio D50-F1 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	50 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Full-Array
Display number of colors	1.073 billion colors
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	-
3D	No
Battery type	AAA
Number of batteries supported	2
Composite video in	0
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Processor cores	8
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 1500, High Dynamic Range 10+ (HDR10 Plus)
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Tuner type	Analog & digital
RMS rated power	10 W
Power consumption (standby)	0.5 W
Power consumption (typical)	71.9 W
Product color	Black
Panel mounting interface	200 x 200 mm
Screw thread	M6
Package depth	151.9 mm
Package width	1270 mm
Package height	760 mm
Package weight	18600 g
Remote control type	XRT136
Operating system installed	SmartCast OS
On Screen Display (OSD) languages	ENG, ESP, FRE

Weight and Dimensions

Depth (with stand)	260.1 mm
Height (with stand)	718.1 mm
Weight (with stand)	13600 g
Depth (without stand)	84.1 mm
Width (without stand)	1129.3 mm
Height (without stand)	657.1 mm
Weight (without stand)	13300 g
