Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult the
LQIRUPDWLRQEHORZWRȴQGWKHDSSURSULDWHPRXQWIRU\RXU79PRGHO
Be sure the mount you choose is capable of supporting the weight of
the TV. After you have determined that you have the correct mount
for your TV, you can begin the installation.
To install your TV on a wall:
 Disconnect any cables connected to your TV.
2. 3ODFHWKH79IDFHGRZQRQDFOHDQȵDWVWDEOHVXUIDFH%HVXUH
the surface is clear of debris that can scratch or damage the TV.
 Remove the stands by loosening and removing
the screws.
4. Attach your TV and wall mount to the wall, carefully following the
instructions that came with your mount. Use only with a UL-listed
wall mount bracket rated for the weight/load of this TV.
For some wall mounts, you may want to use cables
with right-angle connectors. This allows the TV to rest
closer to the wall.
WALL-MOUNT SCREW LOCATIONS
M55-C2
6FUHZ6L]H M6
Hole Pattern: PP9[PP+
:HLJKWZR6WDQG OEV
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
9

Vizio M55-C2 Specifications

General

Screen Type	led
Wall Mount	300mm x 300mm
Features	32 active led zones, clear action 360, v6 six-core processor
Tuner	digital
Screen Size	55 inches
HDR	no
Built-In Speakers	yes
Surround Sound	dts trusurround
Speakers Output	30 watts
Number Of Speakers	2
USB Ports	1
RF Antenna	yes
Network	built-in wi-fi
Headphones Output	no
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	vizio internet apps (v.i.a.)
Remote Control	standard
3D	no
Power Consumption	244.2 kilowatt hours
Depth with Stand	10.01 inches
Height with Stand	30.37 inches
Width with Stand	48.8 inches
Net Weight with Stand	40.24 pounds
Depth without Stand	2.51 inches
Height without Stand	28.03 inches
Net Weight without Stand	39.24 pounds
