VIZIO VL420M/VL470M User Manual
Version 3/25/2009 13
www.VIZIO.com
Chapter 1 Basic Controls and Connections
Front Panel
POWER ‘VIZIO’ LIGHT– The VIZIO name lights white
when powered on and orange when powered off.
REMOTE CONTROL SENSOR – Point the remote
control directly at this window for the best response to
the remote signal.
Side Panel Controls
POWER ( ) – Switch the HDTV on by pressing the button once. Press the
button again to the HDTV off.
MENU – This button activates the On Screen Display (OSD). If a sub-menu is
active, pressing this button will proceed to the next level.
CH
!/ " – Use these buttons to step up or down the TV channels. While the
OSD is active, these buttons function as up and down controls in the OSD
menus.
VOL + / - – Use these buttons to increase or decrease the speaker volume.
While the OSD is active, these buttons function as left and right controls in the
OSD menus.
INPUT (ENTER) – Repeated pressing of this button steps through the input
sources in the following sequence: TV, AV1, AV2, Component1, Component2,
RGB, HDMI1, HDMI2, HDMI3, and HDMI4. Once you have stepped through the
entire sequence, you will return to the beginning. If a sub-menu is active,
pressing this button will return to the previous menu level.
Additionally, when the OSD is active, this button confirms the menu function to
be adjusted.
