28
4.2 Oil/Air Separator Tank
7
2
8
1
4
6
5
9
3
9300140 (Tank Assembly) & 9300056 (Cooler Assembly)
Item
Qty
Part #
Description
1
1
4900128
FTG, STR, #12MORB-#12MJIC, VITON
2
1
4900200
FTG, STR, #8MORB-#8MJIC, VITON
3
1
4900260
FTG, 90, #12MORB-#12MJIC, VITON
4
1
9300090
Assembly, Dipstick, Compressor Oil
5
1
3550691
Assembly, Thermostat 290F
6
1
3600175
Valve, Oil Drain
7
1
3600054
Valve, Safety, 200 PSI
8
1
9300076
Weldment, Tank, Aluminum
9
1
9300056
Assembly, Cooler
