4.3 Compressor and Brackets
1
2
3
4
5
6
P170024 – Assembly, Compressor, S700066
Item
Qty
Part #
Description
1
1
9300071
Inlet Valve, S700066
2
1
5830004
O-ring, Viton, 3 1/8 ID x 1/8
3
1
P170023
Compressor, S700066
4
1
1520573
Bolt, HHCS, M8-1.25 X 20, G10.9 PL
5
1
1570058
Washer, Split Lock, 5/16
6
1
1200559
Bracket, Compressor Brace
