9 - Wheel Bearing Housing
❑ Removing and installing. Refer to
⇒ “13.2 Wheel Bearing Housing, Removing and Installing”, page 202 .
10 - Bonded Rubber Bushing
❑ Replacing. Refer to ⇒ “13.3 Wheel Bearing Housing Bonded Rubber Bushing, Replacing”, page 205 .
11 - Nut
❑ 45 Nm
❑ Always replace if removed
12 - Bolt
❑ 4 Nm
13 - Brake Rotor
14 - Dust Cap
❑ Always replace if removed
❑ Removing and installing. Refer to
⇒ “13.4 Wheel Bearing and Wheel Hub, Removing and Installing”, page 207 .
An appropriate seal can only be achieved with a new dust cap.
15 - Bolt
❑ 200 Nm + 90° turn
❑ Always replace if removed
❑ Loosen and tighten using Socket - Xzn 18mm - T10162A-
16 - Wheel Hub with Wheel Bearing
❑ The ABS sensor ring is installed in the wheel bearing
❑ Removing and installing. Refer to
⇒ “13.4 Wheel Bearing and Wheel Hub, Removing and Installing”, page 207 .
The wheel bearing and wheel hub are installed together in a housing.
This wheel bearing/hub unit is maintenance and adjustment free. Adjusting or servicing is not possible!
17 - Bolt
❑ 12 Nm
18 - Cover Plate
13.2 Wheel Bearing Housing, Removing and
Installing
Special tools and workshop equipment required
♦ Torque Wrench 1332 40-200Nm - VAG1332-
Perform the Following
Removing
– Loosen the wheel bolts.
– Raise the vehicle.
– Remove the wheel.
– Remove the coil spring. Refer to
⇒ “14.2 Coil Spring, Removing and Installing”, page 215 .
– Remove wheel bearing/wheel hub unit. Refer to
⇒ “13.4 Wheel Bearing and Wheel Hub, Removing and Instal‐
ling”, page 207 .
– Remove cover plate.
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
202 Rep. Gr.42 - Rear Suspension
