8.17 Basic Setting for Steering Angle Sensor
- G85-
If the steering wheel is crooked, the Steering Angle Sensor - G85-
basic setting must be checked using the Vehicle Diagnostic Test‐
er .
8.18 Vehicle Data Label
Explanation “PR number” on the Vehicle Data Label
Depending on engine and equipment, various suspensions are
installed. They are identified by the PR numbers.
The PR numbers are needed for the allocation of vehicle specified
values.
Suspension version installed in vehicle is indicated on vehicle
data plate by corresponding PR number for the front axle.
The vehicle data label can be found in the spare wheel well as
well as in the Maintenance booklet.
Sample Vehicle Data Label
In this example the vehicle has basic suspension 2UA -arrow-
installed.
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
8. Wheel Alignment 275
