Tightening Specifications
Component Tightening Specification
Wheel hub with wheel bearing to wheel bearing housing
♦ Use a new bolt
200 Nm + 90° turn
Brake rotor to wheel bearing housing 4 Nm
13.5 Trailing Arm with Mounting Bracket, Re‐
moving and Installing
Special tools and workshop equipment required
♦ Torque Wrench 1332 40-200Nm - VAG1332-
♦ Engine/Gearbox Jack Adapter - Wheel Hub Support - T10149-
Perform the Following
Removing
– Loosen the wheel bolts.
– Raise the vehicle.
– Remove wheel.
– Remove the coil spring. Refer to
⇒ “14.2 Coil Spring, Removing and Installing”, page 215 .
– Remove the rivet inner pin -arrow- and remove the bracket
-1-.
– Remove the coupling rod -1- from trailing arm.
– Remove the bolts -arrows-.
– Mark the mounting bracket installation location on the body.
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
210 Rep. Gr.42 - Rear Suspension
