12 Power Steering Pump, 5-Cylinder
Gasoline Engine
⇒ “12.1 Power Steering Pump, Checking Delivery Pressure ”,
page 363
⇒ “12.2 Overview - Power Steering Pump ”, page 366
⇒ “12.3 Power Steering Pump, Removing and Installing ”,
page 367
12.1 Power Steering Pump, Checking Deliv‐
ery Pressure
Special tools and workshop equipment required
♦ Hose Clamps - Up To 25mm - 3094-
♦ Power Steering Test Unit - VAG1402-
♦ Power Steering Test Unit - Adapter - VAG1402/2-
♦ Power Steering Test Unit - Adapter Hose - VAG1402/6-
♦ Power Steering Test Unit - 110 Degree Fitting - VAG1402/1A-
– Disconnect the intake hose from the reservoir.
1 - Hose Clamps - Up To 25mm - 3094-
– Remove the nuts -arrows- from the return line.
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
12. Power Steering Pump, 5-Cylinder Gasoline Engine 363
