How to Adjust an Inverter Setting
To adjust an inverter setting:
1. Turn the inverter on using the On/Off button if the inverter is off.
2. Press and hold the Display button on the Inverter Controller for 5-10
seconds to enter Settings mode. The following message appears when
in Settings mode:
3. Press the Next button to cycle through available settings and their
currently set values.
4. Press Next until you reach the desired setting that you’d like to change.
Press the Enter button to adjust the setting. An “S” appears in the
display, indicating you can adjust the setting (see example below).
5. Press Next to cycle through the available setting’s values.
6. When you reach the desired setting value, press Enter.
7. The screen will return to the Settings menu and the Read Display LED
will blink twice confirming that a setting has been adjusted/changed
8. To adjust additional settings, follow the previous steps. At any time, press
the ESC button to go back one level, then press Next to continue cycling
through settings.
9. To exit settings mode, press the ESC button until you reach the main
screen with run mode details.
If you adjust several settings, a system restart may be required before changes
take effect. After adjusting settings, you will be prompted to restart the system.
Restarting the Inverter Control Panel
To restart the Inverter Control Panel:
1. Press and hold the Display button on the Inverter Control Panel for 5 to
10 seconds to enter Settings mode.
2. Press the Next button until you reach the Manual Restart screen.
3. Press Enter to perform a system restart.
4. Press ESC to return to the main screen.
