VPS-DOS-TR-06-E / Rev 01
3-May-2022
Volta Power Systems
Page 27 of 41
Settings Screen
A) Settings Adjustment Panel: Displays the adjustable values or toggle
buttons for the corresponding setting.
B) Menu Bar: Touch the menu bar buttons to access the corresponding
screens, including:
– Home button: Accesses the Home screen.
– Alerts button: Accesses the Settings screen.
– Inverter button: Accesses the Inverter screen.
– Sleep button: Puts the Touchscreen into sleep mode.
C) Navigation Arrows: Press to navigate the Settings Panel.
D) Settings Panel: Displays the adjustable settings. Use the arrow buttons
to scroll through the settings, the press the setting to adjust. Refer to
the Available Settings section below for details.
Available Settings
Some screens require a password to edit the settings. These screens include
settings that should only be adjusted by a Volta approved technician. The
following screens have settings that are accessible to all users:
• Screen Timeout: The screen timeout value adjusts the time after
inactivity before the touchscreen turns off. When disabled, the
touchscreen never goes to sleep. Touch the screen to wake up the
touchscreen.
• Units: Toggle the temperature units between °F or °C.
• Date Adjustment: Adjust the date (day, month, year).
• Time Adjustment: Adjust the current time (hour, minute, AM/PM,
12/24 hr).
• Theme: Toggle the touchscreen color theme.
• Screen Brightness: Adjust the screen brightness or toggle between
Auto and Manual mode.
C
D
C
A
B
