Sonic Series
AC EV Charging Station
User Manual
- 13 -
4.3.2. Functional description
Model series
Sonic series
Charging Mode
Mode 3
Charging Control
Remote: “APP-controlled”
Local: “Button-controlled” or “Card-controlled”
Indicator Lights
Multi-color atmosphere lights
Networking interface
WiFi (2.4GHz / 5G Hz), and support OCPP 1.6J Protocol (Optional)
Safety Protection
Surge protection, over temperature, over/under voltage, over current,
leakage fault, ground protection for TN system (TN-C, TN-S and TN-C-
S)
RCD Built-in
Yes, Type B RCMU (meet IEC 62955) built-in
4.3.3. Ambient conditions
Model series
Sonic series
Altitude
≤ 2000m
Storage temperature
-40 ~ 70℃
Operation temperature
-30 ~ 55℃
Relative humidity
≤ 95%RH, no water droplet condensation
Vibration
＜ 0.5G, no acute vibration and impaction
Installation location
Indoor or outdoor, good ventilation, no flammable, explosive gases
4.3.4. Mechanical parameters
Model series
Sonic series
Mounting
Wall-mounted or pole-mounted (mounting pole is optional)
Net Weight
≤ 10
Dimension
H×W×D = 398mm ×210mm × 145mm
Color & Material
Front cover: space gray, PC+ASA; Back cover: Black PC+ASA
IP Code
IP65
IK Code
IK10
