4.2. Model number definition
The model number definition of charging station follows the rules as shown in Fig. 4-3.
HM10
□
□□
Maximum output rated current
16: 16A; 32: 32A
Phase number:
1: 1-phase
3: 3-phase
Product series code
Fig. 4-3 Model number definition
4.3. Specifications
4.3.1. Electrical specifications
Model Number
HM10316
HM10332
HM10132
Rated Voltage
400V, 50/60Hz
230V, 50/60Hz
Rated Current
16A
32A
32A
Rated Power
11kW (@400V, 3-phase)
22kW (@400V, 3-phase)
7kW (@230V, 1-
phase)
Recommended
power supply
cable
5×6mm
2
,copper
5×6mm2,copper
3×6mm2,copper
MCB
recommended
Dedicated circuit, 20A, 4-
Pole
Dedicated circuit, 40A,
4-Pole
Dedicated circuit,
40A, 2-Pole
Input Terminals
L1/L2/L3/ N/ PE
L/ N/ PE
Charging
interface
IEC 62196-2, Type 2, 1-phase (or 3- phase) plug with 5m cable
Note: That cord extension sets are not be used
