Sonic Series
AC EV Charging Station
User Manual
- 20 -
Fig. 5-5 Wall-mounting accessories-E
Drill 3 holes with diameter of 6mm and depth of at least 50mm on the wall using wall-
mounting accessories-E.
◼ Step 2: Fixed the wallbox
As shown in Figure 5-6, use Mounting Accessory-A and Mounting Accessory-B to install
Mounting Accessory-C on the wall;
