Sonic Series
AC EV Charging Station
User Manual
- 33 -
LED indicator
information
⚫ LED flash:
Red×1+Yellow×5
Fault code 15:
Over-temperature
protection
⚫ Check whether the charging station is covered or
installed in a high temperature environment.
LED indicator
information
⚫ LED flash:
Red×1+Yellow×7
Fault code 17:
Leakage protection
⚫ Check whether the charging connector and its
cable are damaged or wet.
⚫ Recover after pulling out the adapter.
⚫ LED flash:
Red×1+Yellow×8
Fault code 18:
Output shortage
⚫ Check whether the charging adapter and its
cables are damaged or wet.
⚫ LED flash:
Red×1+Yellow×9
Fault code 19:
Output overcurrent
⚫ Check whether the charging connector is
correctly connected.
⚫ Check whether the OBC is normal.
⚫ Check the set of output current.
⚫ LED flash:
Red×2+Yellow×1
Fault code 21:
EV response
timeout
⚫ Battery of EV is full. Or the charging connector is
not properly connected.
⚫ Disconnect and reconnect the charging
connector.
⚫ LED flash:
Red×2+Yellow×2
Fault code 22:
EV not supported
⚫ This EV does not meet the IEC standards and
cannot be charged.
⚫ LED flash:
Red×2+Yellow×3
Fault code 23:
Relay sticking
⚫ The device is damaged and needs to be returned
to the factory for repair.
