46
8. DISPLAY INDICATORS AND SYMBOLS
OFF Switch position “Off”, device switches off
Continuity, CON Continuity testing
Insulation Insulation measurement (insulation resistance)
EXT Warning display for external voltage
PI Calculation of the polarization index
DAR Calculation of the dielectric absorption rate
TRUE RMS Actual effective value measurement
ZERO Zeroing for the low-ohm measuring range “Ω”
SAVE Internal memory cells (max. 99), save measured value
RECALL Read measured value from memory
rECA Memory display is activated
FUL All 99 memory cells are occupied
CLR All memory cells are free
CLEAR Delete memory cells
TEST Button for triggering measurement, display of the active insulation
measurement
> Greater-than sign
COMP Activates the comparison function with good/bad display
NG Symbol for bad display (NG = Not Good)
PASS Symbol for good display
LOCK Switch long-term measurement function on and off
Long-term measurement function is active
TIME Preselect times for time-controlled measurement function
15s, 30s, 60s, Time display in seconds
1min, 10min Time display in minutes
