Attention!
The max. input or measuring voltage must no exceed
30Veff.
The minimum input sensitivity is < 1MHz 300mVeff
and > 1MHz 600mV.
Disposal
If the digital multimeter fails to function with the proper supply volta-
ge and fuses or it cannot be repaired, it must be disposed of in
accordance with the applicable legal provisions.
Troubleshooting
With this Digital Multimeter VC – 260 you have purchased a product
designed in accordance with the latest state of the art. Problems
and disturbances may, however, still arise. Therefore, a description
follows of how to eliminate some of these faults relatively easily
yourself. Do not fail to observe the safety instructions!
Fault Possible cause
Measurement of current Fuses for the current ranges OK?
not possible Are the measuring lines correctly
connected to the measuring sockets?
Are the measuring cables connected
to the A or µA/mA-socket and COM?
No display if the Is the capacitor discharged?
device is turned on
When was the installed capacitor char-
ged for the last time?
Has the measuring instrument been
turned off automatically after not being
used for 30 minutes?
42
