7. OPERATING ELEMENTS / SYMBOLS
a) Current clamp
No. Name
1 Current clamp
2 NCV signal display
3 Rotary switch for selecting the
measuring function
4 SELECT/V.F.C button
5 LCD display
6 Battery compartment (back)
7 COM -measuring socket
8 V-measuring socket
(
V Ω)
9 ZERO button
10
HOLD/
button
11 Opening lever
100A
CAT II
600V
CAT III
300V
1
3
4
5
6
9
10
11
8
2
7
I
J
K
M
N
A
C
D
B
H
E
FG
L
