52
Repair of MS2V reverse gear, angle gear
5. Remove the seal ring.
NOTE! The seal ring must always be replaced by a
new one.
6. Press the bearing race out of the housing. Use tool
no. 884856 and shaft 884859. Save the shims be-
neath the bearing race.
7. Screw two screws into the tubular shaft and fix it by
putting the two screw heads in a vise. Undo the tubu-
lar nut with a hook wrench. When the tubular nut is re-
moved, remove the outer ball bearing as well. Please
refer to item 8.
8. A claw extractor must be used to free the bearing
fully from the tubular shaft. Grip round the tubular nut.
884859
884856
