Specifications
114 Electrical system
Relay
Fuses
Fuse for cabin equipment
NOTE! Use only fuses of specified capacity (Ampere rating).
No. Relay Relay function
1 R1 Engine preheating
2 R2 Starting the engine
3 R3 Working headlights/lighting system
No. Lock Ampere Function
1 FU 20A 20 A Electric power supply for control unit
2 FU 20A 20 A Electric power supply for control unit
3 FU 5A 5 A Electric power supply for control unit, engine preheating relay
4 FU 20A 20 A Electric power supply for lighting relay
5 FU 15A 15 A Electric power supply for cab
6 FU 15A 15 A Rotating beacon, horn, hand lamp
No. Lock Ampere Function
7 FU 3A 3 A Radio
8 FU 7.5A 7.5 A Windscreen wiper, windscreen washer system
9 FU 5A 5 A Cab light
10 FU 5A 5 A Radio with tape player
11 FU 7.5A 7.5 A Cabin heating
