113
ECS Gen. 2
ECS Gen. 2 main
components
1. Pressure sensor 4. Solenoid valve - drive axle
2. ECS ECU 5. Height sensor
3. Solenoid valve - 6. Solenoid valve - trailing axle
front axle
