153
ECS Gen. 2
Pressure sensors
ECS Gen. 2 systems have four pressure sensors (five if
front air suspension is fitted):
B24 - lift axle lifting bellows
B55 - lift axle suspension bellows
B56 - front axle bellows
B57 - drive axle bellows RH
B58 - drive axle bellows LH
This allows the pressure in each individual circuit to be
separately monitored.
This means that the pressure control valve is not needed,
Pressure vs.
voltage
Sensed pressure - bar Voltage to ECU
1 0.8
3 1.5
5 2.2
7 2.8
9 3.5
11 4.2
