85
ECS Gen. 1
Changing
chassis height in
interlock mode
If it is necessary to change the chassis height before the
fault is corrected, select the location to be changed, and set
the control and axle switches as shown in the chart above.
Note: Because of the design of the solenoid block used
on 4x2 tractors (i.e. ports 21 and 22 are controlled by a
common solenoid valve) individual control of LH and RH is
not possible.
The settings arrived at using switch (2) in M1 or M2
position, can be stored in memory, and recalled, using
button (4).
To store a setting, press the button for more than 5 sec.
To recall a setting, press the button for less than 2 sec.
Memory - store
and recall
