43
ECS Gen. 1
component
locations
ECS Gen. 1
1. ECS ECU - 9073
2. Remote control - 9009, 9010
3. Height sensor - 7072
4. Test nipple
5. Air bellows - front axle
6. Distribution manifold - extra equipment (axle lift bellows)
7. Safety valve
8. Wet tank
9. Test nipple
10. Solenoid valve block - front axle - 6035LF
11. Solenoid valve block - drive axle - 6035C
12. Solenoid valve block - bogie - 6045
13. Overflow valve - 52a and 52b
14. Air bellows - drive axle
15. ECS air tank
16. Air bellows - trailing axle
17. Lift bellows - taring axle
