21
General information
Air suspension
air supply
The main components in this circuit are:
1 Compressor
1a Safety valve
2a Air dryer
2b Regeneration tank - not with AIRDRY-E, version 2
trucks
14 Wet tank
23 Test point
24 Multi-circuit protection valve (MCPV)
50 Air suspension air tank
51 Pressure limiting valve
52a Overflow valve - 6.7 - 7.0 bar
52b Overflow valve - 10.0 - 10.4 bar
ECS To ECS solenoid valve blocks
