Volvo ECS - Gen. 3 Introduction and Components

184
ECS Gen. 3
ECS Gen. 3
component
locations
ECS generation 3 was introduced week 51 2004.
The principle of operation is the same as previous
generations, but new components are used:
- ECS ECU
- height sensors
- pressure sensors
- solenoid valves
New Service Information is included in IMPACT Group 72.
1. ECS ECU
2. Height sensor
3. Pressure sensor
4. Solenoid valve
5. Air bellows
ECS Gen. 3
introduction
