Air bellows
General information
1. Air supply from the solenoid valve block
2. Attachment screw
3. Bellows plate
4. Hollow rubber damper
5. Air bellows
6. Plunger
7. Guide pin
Bellows plate (3) is attached to the frame, and plunger (6)
is attached to the axle.
During normal suspension movement, and during frame
height change, rubber air bellows (5) rolls up and down
plunger (6).
If the bellows is fully compressed - due to e.g. loss of air
pressure, high speed cornering, very uneven surfaces - the
load is carried on damper (4).
