186
ECS Gen. 3
Remote control
Gen. 3 remote control contains a micro processor, and has
9 terminals.
Operation of this control is similar to that for previous
controls, but the selector button ʻtogglesʼ through the
functions, and the LED indicates which function has been
selected.
A new feature is the ʻSTOPʼ button.
If a function is started, and then a dangerous situation
develops, pressing the ʻSTOPʼ button immediately cancels
the selected function.
The Gen. 3 control can be used with Gen.1 and Gen. 2, but
needs connection of an additional wire to power the LEDʼs
via the 5V supply to the sensors.
